Updated BOM for Odin Kits:
While working through the BOM to create these kits, some issues or missing parts were found that have been updated in the below BOM. Original IDs from the Manuel have been kept to prevent confusion from these documents.
See updated BOM below:
| Part Number: | Description: | Qty: | Source: | Price
(As of 4/1/2026): | | ODIN-HW-01 | 1.5mm x 45mm Smooth Rod | 4 | Amazon | $5.49 | | ODIN-HW-02 | M3 x 61mm Threaded Rod | 1 | 94595A215 | $3.41 | | ODIN-HW-03 | M3 x 14mm SS | 1 | 93245A416 | $12.91 | | ODIN-HW-04 | AR15 Mag Catch Spring | 1 | KAK | $2.00 | | ODIN-HW-05 | M3 Locknut | 1 | 90576A102 | $5.55 | | ODIN-HW-06 | M3 x 65mm SHCS | 1 | 91292A315 | $13.23 | | ODIN-HW-07 | 3mm x 115.5mm Smooth Rod | 2 | 8920K14 – 1ft | $2.33 | | ODIN-HW-08 | 3″ Spring | 2 | 9637K41 | $14.59 | | ODIN-HW-09 | M8 x 50mm SHCS | 1 | 91290A448 | $9.37 | | ODIN-HW-10 | M3 x 48mm Threaded Rod | 1 | In HW-02 | | ODIN-HW-11 | M3 x 70mm SHCS | 1 | 91292A316 | $13.70 | | ODIN-HW-12 | M3 x 6mm SS | 1 | 91217A065 | $4.83 | | ODIN-HW-13 | M3 x 20mm Dowel | 2 | 91595A122 | $12.30 | | ODIN-HW-14 | M3 Locknut | 1 | In HW-05 | | ODIN-HW-14a | M3 Locknut | 1 | In HW-05 | | ODIN-HW-15 | 1/4×28 3″ SHCS | 1 | 91251A467 | $11.86 | | ODIN-HW-16 | 3mm x 60mm Smooth Rod | 1 | In HW-07 | | ODIN-HW-17 | 1/4×20 x 6.25″ SHCS | 2 | 91251A562 | $7.18 | | ODIN-HW-18 | M3 x 14mm SHCS | 1 | 91290A119 | $15.30 | | ODIN-HW-19 | 1/4×20 322.6mm Threaded Rod | 2 | 90322A649 | $5.05 | | ODIN-HW-20 | 1/4×20 Locknut | 4 | 97135A414 | $4.76 | | ODIN-HW-21 | M3 x 4mm SHCS | 1 | 91290A109 | $3.86 | | ODIN-HW-23 | M3 Nut | 10 | 90592A009 | $1.50 | | ODIN-HW-24 | M3 x 14mm SHCS | 10 | In HW-18 | | ODIN-HW-25 | 3mm x 36mm Dowel | 1 | 91595A140 | $13.04 | | ODIN-HW-26 | 8″ Barrel | 1 | Online Metals | $12.41 | | ODIN-HW-27 | 3mm x 50mm Dowel | 5 | 91585A491 | $9.00 | | ODIN-HW-28 | M3 x 14mm SS | 1 | 92605A717 | $12.41 | | ODIN-SCS-01 | Threaded Plate | 1 | SCS | $27.11 | | ODIN-SCS-02 | Plate | 1 | SCS | $20.27 | | ODIN-SCS-03 | Metal Spline | 1 | SCS | $12.36 | | ODINSTCK-HW-01 | M5 x 40mm BHCS | 2 | 94500A302 | $19.53 | | ODINSTCK-HW-02 | M5 Nut | 2 | 94150A340 | $6.68 | | ODINSTCK-HW-03 | M4 x 30mm SHCS | 2 | 91290A180 | $10.37 | | ODINSTCK-HW-04 | M4 Locknut | 2 | 90631A112 | $5.03 | | ODINSTCK-HW-05 | M4 x 10mm SS | 1 | 91217A125 | $3.83 | | ODINSTCK-HW-06 | 5mm x 140mm Smooth Rod | 2 | 8920K18 | $2.50 | | ODINSTCK-HW-07 | 6mm x 22mm Dowel | 1 | 91595A455 | $13.35 | | ODINSTCK-HW-08 | M6 x 20mm BHCS | 2 | 91306A673 | $8.93 | | ODINSTCK-HW-09 | M6 x 7.6mm Heatset | 2 | 94180A371 | $14.40 | | ODINSTCK-HW-10 | 5″ Spring | 1 | 9657K268 | $9.48 |
| | | | |
| | | | |
